Inline Enclosure PP06

Fibre optic inline enclosure IP68 rated with 4, 8 or 12 cable entries and up to 384 fibres


Datasheet

Categories: , Tag:

Description

Inline Enclosure PP06 features a unique stackable design, allowing the unit to be extended creating more cable entries, higher capacity and more room for cable management.

Inline Enclosure PP06 is the largest capacity inline enclosure in our range but it can also be reduced in size for applications where less splices are needed. Great value for money considering the flexibility, capacity and IP68 rating. Great for applications where a large number of cables need to be spliced


Features & Benefits

  • Up to 288 fibres
  • 4, 8 or 12 cable entries
  • Accepts up to 22mm diameter cables
  • Protects fibre splices in the field
  • Can be aerial, wall and duct-mounted
  • Suitable for direct burial
  • IP 68 rated
  • Reusable Silica gel seal in order to ensure an airtight, waterproof performance
  • No special tools required
  • Mechanical sealing
  • Made with high-strength plastic, PC, which prevents aging from cold, heat, oxygen and ultraviolet radiation
  • Dimensions: 435 * 190 * 120mm

Applications

  • Premise installations and telecommunication networks
  • Ethernet, fibre channel, ATM, LAN, MAN and WAN
  • Data communication
  • Outdoor applications
  • Duct mountable and direct burial
  • FTTH
  • Water submersible

Ordering Information

Part Number Selection

Generated Product Code:

LXMPP06INLXXM

Replace the XX in the product code with the fibre capacity required.
