6U 19″ 600x550mm Double Door Wall Mounted Cabinet Model B -Black (Assembled)

SKU: LXMBBLK6506 Categories: , , Tag:


Linxcom 6U 19″ 600x550mm Double Door Wall Mounted Cabinet is a cost-effective solution that is both aesthetically pleasing and durable.

Designed to be installed in data centres, equipment rooms and office environments to mount telecommunication, data communication, security, broadcasting and other electronic equipment.

The 6U 19″ 600x550mm Double Door Wall Mounted Cabinet model B is double section welded design with lockable single front glass door and solid back panel with mounting bracket.

Model B is 600mm wide, 550mm deep and up to 15U capacity. This cabinet can hold up to 60kgs UDL.

This cabinet is ready-built and in any RAL colour on customer’s specification. Black colour as standard.


  • Toughened 5mm glass front door
  • Lockable front door
  • Black powder-coated finish
  • Lockable Back Door
  • Vented top and bottom panels and door for improved airflow
  • Max 60kgs UDL loading capacity
  • 1.2mm cold-rolled steel body
  • Mounts standard 19″ equipment
  • Front and rear mounting profiles
  • 2x 120mm fan cut-outs
  • Earthing Wire
  • Section Front and Rear Access.
  • Cable Entries: 2 – 1x Top, 1x Bottom, Knock-out Plates
  • Mounting Profiles: Front and Rear
  • Lockable Doors: Front, Side, Back Doors
  • Compatible with Castors: No

Accessories for cabinets are available on the following page
