12U 19” 570x300mm Wall Mounted Cabinet Model E – Black (Flat-Pack)

SKU: LXMEBLK5312/F Categories: , , Tag:


Linxcom 12U 19” 570x300mm Wall Mounted Cabinet is a cost-effective solution that is both aesthetically pleasing and durable.

Designed to be installed in data centres, equipment rooms and office environments to mount telecommunication, data communication, security, broadcasting and other electronic equipment.

The 12U 19” 570x300mm wall mounted cabinet model E is single section with lockable single front glass door and solid back panel with mounting bracket.


  • Cabinet Dimensions: Front Rail to Back Rail – 150mm
  • Cabinet Dimensions: Front Rail to Back of Cabinet – 210mm
  • Toughened 5mm glass front door
  • Lockable front door
  • Black powder-coated finish
  • Flat-Packed, some assembly required
  • Tool-free changing of front door orientation
  • Vented top and bottom panels and door for improved airflow
  • Max 60kgs UDL loading capacity
  • 1.2mm cold-rolled steel body
  • Mounts standard 19″ equipment
  • Front mounting profiles
  • 2x 120mm fan cut-outs
  • Grounding Screw
  • Cable Entries: 2 – 1x Top, 1x Bottom
  • Mounting Profiles: Front Only
  • Lockable Doors: Front Only
  • Compatible with Castors: No
  • Additional Cage Nuts: 10 Sets

Accessories for cabinets are available on the following page
